Axiom – Vacuum Hold-Down Kit (5 pods)
Regular price
$229.00
Couldn't load pickup availability
Item out of stock? - Call us and we'd be happy to reserve one for you when the next batch arrives!
Questions? - We are here to help!
Call us at 1-877-231-342
or local at 204-231-3429
Securing your workpiece to the bed of your CNC router often creates a challenge. The Axiom vacuum hold-down kit is a terrific accessory which makes securing your part a snap. Use just one pod to secure a small part, or all five pods to hold something large.
These compact Vacuum Pods are made from clear acrylic, each with it’s own vacuum seal. Each pod is connected together to cover a large area. Place the pods on your Axiom CNC table and secure with screws and T-nuts (included). Pods can be mounted either on top of your MDF spoil board or directly to the aluminum table by selecting the appropriate length screws. Cut the 1/4" hose to the desired length and connect the pods and valve to the vacuum port on the venturi. Use the remaining hose and fitting to connect your compressor to the air port on the venturi.
You'll be amazed of the holding power of this exciting NEW accessory!
Included:
• Vacuum Pods (5 pcs)
• On/off valve
• Venturi vacuum pump
• Mounting hardware
• End cap
• Hose (200")
• Air fitting
• Replacement gasket material
Note: requires 1.5CFM of compressed air at 90PSI
These compact Vacuum Pods are made from clear acrylic, each with it’s own vacuum seal. Each pod is connected together to cover a large area. Place the pods on your Axiom CNC table and secure with screws and T-nuts (included). Pods can be mounted either on top of your MDF spoil board or directly to the aluminum table by selecting the appropriate length screws. Cut the 1/4" hose to the desired length and connect the pods and valve to the vacuum port on the venturi. Use the remaining hose and fitting to connect your compressor to the air port on the venturi.
You'll be amazed of the holding power of this exciting NEW accessory!
Included:
• Vacuum Pods (5 pcs)
• On/off valve
• Venturi vacuum pump
• Mounting hardware
• End cap
• Hose (200")
• Air fitting
• Replacement gasket material
Note: requires 1.5CFM of compressed air at 90PSI
