PERFECT EXECUTION AND EXTRAORDINARY DURABILITY WITH THE NEW HIGH QUALITY CMT TIPS!
CMT has produced a new range of tools that can amaze even the most skeptical buyer. These are the main features:
- Special carbide in micrograin.
- New design of reinforced engravers that allows better finishes at higher feed speeds.
- The solid carbide construction ensures greater centering, less breakage and a high number of resharpening.
Perfect on all materials, ideal on hard and soft natural woods and its derivatives also chipboard and laminates, MDF and plastic materials. Very high performance on high-speed drilling machines, point/point machines and CNC pantographs.
SPECIFICATIONS:
- Attachment made of special high-strength steel.
- Helical body in super micrograin carbide of superior quality.
- Centering tip.
- 2 cutting edges (Z2).
- 2+2 helical grooves.
- 2 engravers with reinforced sharpening (V2).
- Connection with fixing plane and screw for axial adjustment.
For blind holes on solid wood and its derivatives, whether or not laminated.
To be inserted on spindles or adapters in drilling machines.
HWM = Solid Carbide
RH = Clockwise
LH = Counter Clockwise
| Item # | D | I | L | S | Z | Mat. | RH/LH |
| 311.030.21 | 3 | 18 | 70 | 10x40 | 2 | HWM | RH |
| 311.030.22 | 3 | 18 | 70 | 10x40 | 2 | HWM | LH |
